8S1A CPU
The 8S1A is an 8-bit microprocessor for Minecraft. It includes 128 bytes of memory built-in, and features 9 instructions.
IMPORTANT
This world was made in 1.13. Since 1.13 adds a new world layout system, it is impossible to load this world in 1.12 or below. This also means that you cannot copy the CPU into a pre-existing world without copying in the region file manually. Do NOT try to load the world in 1.12, or you WILL experience data loss. (You can always download a new copy of the CPU, though.)
Interface
Going from left to right, the pins are:
Instruction | Instruction Done | Output Bits | Input Bits | Clock In | Clock Out | Memory Clear |
---|---|---|---|---|---|---|
Type | Pulse | Steady | Steady | Pulse | Pulse | Pulse |
Input/Output | Output | Output | Input | Input | Output | Input |
Symbol | IND |
OUT |
INP |
CKI |
CKO |
MAC |
Each pulse is expected to be at least 4 ticks long.
How to Use
First, make sure to connect INP
, OUT
, CKI
, and CKO
to wherever they are going to, such as levers and lamps. (A good way to send parallel lines for INP
and OUT
is to alternate {block, redstone, block, repeater}. This will keep the delay at 1 tick/4 blocks and doesn’t cause any interference.) Make sure that the CKI
wire has the same delay as the input, or you may end up sending a clock before the input is ready.
Next, send the input instructions over INP
. Once the required number is going through the input, send a pulse of 4 ticks to CKI
. Maintain the signal over INP
until a pulse is sent over CKO
. Once CKO
pulses, the CPU is ready to accept another byte of data.
When the CPU is done executing a full instruction, a pulse will be sent over IND
. This is not necessary to use the CPU, but it can be helpful when creating instruction extensions for the CPU. (More on that later.) This signal indicates that the CPU is ready to accept another instruction.
If you want to reset the memory of the CPU, send a pulse over MAC
. This will clear the entire 128 bytes of memory, as well as OUT
and the result buffer. Note that no pulse will be sent over CKO
when done, but if OUT
is not zero it will change. You can use that as an unreliable way to detect when it is done if needed. But to be safe, wait at least 30 ticks to send more input.
Instruction Set
Value | CPU Name | Full Name | Arguments | Description | Caveats |
---|---|---|---|---|---|
0x00 | ADD |
Addition | <a1> <a2> |
Adds a1 and a2 together and stores the output in the result buffer (0x00 ). |
None |
0x01 | SUB |
Subtraction | <m> <s> |
Subtracts s from m and stores the output in the result buffer (0x00 ). |
None |
0x02 | SET |
Memory Set | <addr> <val> |
Sets the memory address at addr to val. | You cannot set address 0x00 (result buffer) because this is the default address, and buggy things may happen. Also, you cannot copy values directly in memory (except for address 0x00 ), but you can replicate it by adding 0 to the value and setting from the result buffer: ADD 0x7E <addr1> SET <addr2> 0x7E 0x00 . |
0x03 | IEQ |
If Equal | <n1> <n2> <instr...> 0x7D |
If n1 and n2 are equal, anything in instr is executed. If not, does nothing until it recieves 0x7D . |
Make sure to pass 0x7D at the end of the if unless you are 100% sure that n1 == n2 . (But in that case, why are you using if at all?) |
0x04 | INE |
If Not Equal | <n1> <n2> <instr...> 0x7D |
If n1 and n2 are not equal, anything in instr is executed. If not, waits until it gets 0x7D . |
Same as IEQ |
0x05 | IGT |
If Greater Than | <n1> <n2> <instr...> 0x7D |
If n1 is greater than n2 , anything in instr is executed. If not, waits until it gets 0x7D . |
Same as IEQ |
0x06 | ILT |
If Less Than | <n1> <n2> <instr...> 0x7D |
If n1 is less than n2 , anything in instr is executed. If not, waits until it gets 0x7D . |
Same as IEQ |
0x07 | OUT |
Output | <num> |
Sends num to the output. |
When reading from memory, there is a very precise timing on the output, so it may not work on slower (real) computers. |
0x7E | $ * |
Memory Read | <addr> |
This instruction can be used anywhere in a program. It will replace whatever argument it is in the place of with the value of addr . |
Cannot be used in conjunction with SET because both are accessing the memory unless 0x00 is being read. |
* Symbol used in assembly
For experts
Extending Instructions
You can easily extend the instruction set of the CPU. By adding a circuit to detect new instructions, you can easily extend the functionality of the CPU. I am planning to release a memory extension unit which will add a 16-bit address bus and four new commands allowing the CPU to run instructions from memory.
Here’s an outline of how you can create your own instructions:
- Create an XOR equality checker inline with the input to check if the number is the same.
- Attach the XOR to an RS-NOR latch to only look for instructions when the CPU is waiting for instructions.
- Use the
IND
wire to turn off the RS-NOR, and turn on when an instruction is sent. - Set up a way to allow the signal to go to the instruction only when the instruction is selected, and disable this when it is not.
You can look at the main selection circuitry inside the CPU to see how it is done inside.
Writing assembly code
I have written an assembler for the 8S1A (technically, it’s for the memory expansion, but it still works) in the assembler
branch of this repository. I have included build instructions there to be able to write programs.
ROM chip
I will be writing instructions on how to build your own ROM from assembled code soon. The ROM will be coming before the memory unit.
Distribution
You are allowed to freely copy and redistribute this processor as long as you do not try to say that it’s your creation. Honestly, I have no way to really enforce any licensing policy, but it’s the good thing to do. :)
